AC Infinity Duct Carbon Filter, Australian Charcoal, 1308 m3/h, 200 mm

Product detailed description

Filter for high-capacity 200 mm systems

AC Infinity DCF8 is an inline carbon filter with a 200 mm flange diameter for larger grow tents and more demanding air extraction systems. It removes odours and chemicals from extracted air and withstands long-term operation in both intake and exhaust configurations.

Carbon bed and adsorption

The filter media consists of Virgin Australian activated carbon (Virgin Australian RC412) rated at 1200+ IAV in a 38 mm layer. The maximum air flow rate is 770 CFM (1308 m3/h).

Durable construction for humid environments

The flange is made of aluminium and reversible on both sides, and at 8.6 cm long, it is one of the longest in the DCF range. The grille is made of galvanised steel with a corrosion-resistant gunmetal finish (dark grey).

Package contents and installation

• 1x DCF8 carbon filter
• 2x straps
• 2x rope clip hangers
• 2x washable pre-filters
• Flange diameter: 200 mm | Filter length: 50.8 cm | Overall dimensions: 46.0 x 27.7 cm | Flange length: 8.6 cm

Choose the right fan and accessories (200 mm)

Pair the DCF8 filter with a fan and ducting of the same 200 mm diameter. Carbon in the ducting creates resistance and reduces the actual system flow rate, so choose a fan with capacity above the grow tent's requirements:

• AC Infinity CLOUDLINE S8 - fan with a 10-step speed controller.
• AC Infinity CLOUDLINE T8 - fan supplied with a VPD Controller 69 Pro.
• Flexible four-layer ducting 200 mm - connects the filter to the fan.
• Pre-filter for 200 mm carbon filter (2 pcs) - replacement set.

Frequently asked questions

Which fan is the DCF8 filter suitable for?
It has a 200 mm flange and is suitable for CLOUDLINE S8 and T8 fans of the same diameter.

Must the filter have the same or higher flow rate than the fan?
Do not compare this solely by the filter rating. The 200 mm CLOUDLINE fan has a stated maximum flow rate of 807 CFM (approximately 1371 m3/h), while the DCF8 has 770 CFM (1308 m3/h) - the values are close. The filter also reduces the actual system flow rate due to carbon resistance, so choose a fan with reserve capacity.

Why does the DCF8 have a longer flange than the other sizes?
The DCF8 flange measures 8.6 cm, which is significantly more than the other sizes in the range (3.7-5.2 cm) - making it easier to connect ducting of the same diameter.
