AC Infinity UIS Lighting Adapter Type-B, for RJ11/12 Connector Lights with Resistor Dimmers

Product detailed description

Adapter for third-party LED lights with older resistor dimmer

AC Infinity UIS Lighting Adapter Type-B is an adapter dongle that allows UIS controllers to control grow lights from other brands with an RJ11 or RJ12 connector - specifically those using older resistor dimming technology. It therefore differs from Type-A, which is intended for newer PWM or 0-10V dimmers. One end is UIS male for connection to the controller port, the other end is RJ11/RJ12 female for connecting the light.

How to tell whether Type-B is right for your light

Type-B works only with lights with an RJ11/RJ12 connector and a resistor dimmer. Lights with spectral control or with a PWM/voltage protocol are not compatible - Type-A is intended for those. After connecting the first light, additional RJ11/RJ12 lights of the same brand can be linked in a daisy chain according to the manufacturer's procedure.

What the adapter allows

The package also includes a separate 10-foot (approx. 3 m) RJ11/12 extension cable. Another UIS device is needed to power the controller itself. For some brands, a firmware update via the AC Infinity app may be required.

Technical specifications

• Male connector: UIS
• Female connector: RJ11, RJ12
• Adapter length: 25.4 cm (10 in)
• Extension cable included: 10 ft (approx. 3 m), RJ11/12
• UIS connector depth: 0.7 cm

Compatible controllers and light brands

Controllers: CONTROLLER 69, CONTROLLER 69 WiFi, CONTROLLER 69 PRO, CONTROLLER AI+. Compatible brands (the list is expanding): CHILLED TECH (GROWCRAFT with Push-Lock Dimmer to RJ12 adapter GC-DIM-TM-RJ12-1), HLG (all models with RJ 0-10V dimming box, including the Inventronics driver), MARS HYDRO (FC, FC-E, SP, TS with MOSO/Meanwell driver), MIGRO (ARAY), SPIDER FARMER (SE, SF with MOSO/Meanwell driver).

Frequently asked questions

How do I know whether my light needs Type-B rather than Type-A?
Type-B is for lights with an RJ11/RJ12 connector and an older resistor dimmer. Mars Hydro or Spider Farmer models with a MOSO/Meanwell driver belong to Type-B, while the same brands with a self-branded driver belong to Type-A.

What if my light has a different dimmer than a resistor one?
For a PWM or 0-10V dimmer, use Type-A. For a light without an RJ connector, but with dim +/- wires on the driver, use Type-D.

Does the adapter include an extension cable?
Yes, the package includes a separate 10-foot (approx. 3 m) RJ11/12 extension cable.
