AC Infinity IONFRAME EVO6, Samsung LM301H EVO LED Grow Light, 500W, 1.2x1.2m

Product detailed description

Top LED lighting for your plants

AC Infinity IONFRAME EVO6 represents a revolution in growing under artificial lighting. With an output of 500 W and the use of the latest Samsung LM301H EVO diodes, this light is designed to achieve maximum yields and the health of your annual plants, such as tomatoes, herbs or chilli peppers, over an area of up to 120x120 cm.

The latest Samsung LM301H EVO diode technology

The heart of this system is the top-quality Samsung LM301H EVO diodes, which boast an impressive efficiency of 3.14 µmol/J PPE. This technology outperforms older models such as LM301B or LM301H and guarantees higher light intensity and a better spectral response, leading to faster and more vigorous growth of your plants.

Thoughtful design for perfect coverage

Thanks to the bar construction and algorithmically placed diodes, IONFRAME EVO6 provides absolutely even coverage of the growing area without the formation of hot spots (so-called hotspots). The modular design also allows the driver to be disconnected and placed outside the growing space, which contributes to better heat dissipation and flexibility during installation.

Intelligent control and full automation

The package includes an advanced controller that allows full control over your lighting. You can set timers, adjust brightness in 10 levels or simulate the natural sunrise and sunset cycle. For maximum convenience, the light is compatible with the UIS™ platform, which enables control via Wi-Fi and full automation through the AC Infinity app. In addition, you can connect up to 80 lights in one chain.

Complete spectrum for every stage of growth

IONFRAME EVO6 provides a carefully tuned spectrum that supports plants from germination to harvest. In addition to the basic 3000K and 5000K diodes, it also includes:

• UV diodes (395 nm) to stimulate resin production and the plants' defence mechanisms.
• OSRAM deep red diodes (660 nm) to support photosynthesis and flowering.
• OSRAM far red diodes (730 nm) to improve plant health and overall vitality.

Durability and safety first

The robust steel and aluminium construction ensures effective passive cooling and a long service life. The light has an IP-65 rating, which guarantees resistance to dust and moisture, making it ideal for demanding grow tent conditions. Operational safety is confirmed by ETL certification (No. 5021417).

Technical specifications and dimensions

• Light dimensions: 82.0 x 83.0 x 8.6 cm
• Ideal coverage for flowering: 120 x 120 cm
• Ideal coverage for growth: 150 x 150 cm
• Power input: 500 W
• Efficiency: 3.14 µmol/J
• PPFD: 1991 µmol/s/m²
• Diodes: Samsung LM301H EVO, OSRAM, Seoul
• Total number of diodes: 1680
• Spectrum: 395 nm, 660 nm, 730 nm, 3000K, 5000K
• Voltage: 100-277V AC
• Service life: 50,000 hours
• Protection rating: IP-65
