Trolmaster Substrate Sensor Set (VWC, EC & Temp) (WCS-9)

Product detailed description

TrolMaster WCS-9 Substrate Sensor is a 3-in-1 sensor designed for Aqua-X, Hydro-X, Tent-X and Green-X Control Systems (NFS-1, NFS-2, NFS-3, HCS-2, TCS-1, GCS-1). It is used for precise monitoring of the substrate in soil and in inert substrates with a higher EC value.

Unlike standard measurement with a single sensor, the WCS-9 allows up to four Sensor Nodes to be connected to one Sensor Display. Thanks to data collection from multiple points in the growing medium, the system provides more accurate average values in the root zone, including water content (VWC- Volumetric Water Content), EC and temperature.

Before connecting the WCS-9 to the control unit, the firmware must be updated.

Features:

• precise substrate measurement
• aggregation of data from multiple measuring points
• advanced Daisy-Chain connection
• dynamic measurement intervals
• simplified calibration
• support for Feed on Demand control
• scalable solution with free app access

Package contents:

• 1× WCS-9 Sensor Display
• 1× WN-9 Sensor Node
• 1× 16ft RJ12 Cable Set
• 1× T-Splitter

Technical specifications:

• Input voltage: 12 V / 0.1 A
• Max. input current: 0.1 A
• Water content range: 0–100 %
• EC range: 0–30 mS/cm
• Measurement range: 0–50 °C (32–122 °F)
• Operating temperature: 0–50 °C (32–122 °F)
• Operating humidity: ≤90 % RH
