Prima Klima PK-Kombo 125-TC - 400 m3/h, fan and filter
Code: 25983Related products
Product detailed description
The Prima Klima Kombo Kit with PK125-TC fan (with temperature-controlled speed control) and Eco lineK2601 Flat-125 activated carbon filter is one of the most efficient and quietest filtration systems in the world.
The Prima Klima fan has
- temperature-dependent speed control adjustable from 20 to 30 degrees (if the temperature exceeds the set temperature, the fan spins more)
- minimum speed setting from 0 to 100% (at 100% the temperature-dependent control does not work)
- automatic thermal protection of the motor
- circular connection for connecting 125 mm diameter pipes
- built-in thermal sensor
- integrated cable with plug
Advantages of the fan
- quiet EBM-Papst RadiCal motor with ball bearings
- automatic speed control according to room temperature
- aerodynamically shaped blades curved backwards
- housing made of impact-resistant and heat-resistant material (polyamide nylon plastic)
- low consumption, low noise level, light weight
- easy installation with included mounting brackets
- operating mechanism protected by cover
- sensor on four-meter cable
- fan including cable with plug
The fan has a sufficiently long cable with a probe that allows you to measure and then adjust the temperature in a specific location. After setting the min fan speed and max temperature "on the probe", the fan runs at reduced power until the temperature reaches the maximum you set, as the temperature continues to rise the thermostat switches the fan full power to 100%, the fan runs until the temperature is reduced again below the maximum you set, then the fan speed is automatically reduced again to the set value e.g. 40% power.
Parameters
- Maximum operating temperature is 65 °C.
- Weight: 2.3Kg
- Dimensions: 244x220 mm
- Power cable included
Technical details Prima KlimaK2601 FLAT - 440 m3/h - 125
- Flange: 125 mm
- Length: 250 mm without flange
- Diameter: 230 mm
- Max. air flow: 440 m3/h
- Optimal air flow: 360 m3/h
- Including pre-filter: K2701 flat
- Weight: 3 kg
- Activated carbon: 1.6 kg
Additional parameters
| Category: | Prima Klima Ventilators with Speed Control and Thermostat |
|---|---|
| Flange (mm): | 125 |
| Speed Control: | Smooth speed regulation and thermostat |
| Technology: | Radial |
| Airflow (m3/h): | 400 |
| ? Engine type: | AC |
| PFHGX: | Levné, Nejprodávanější, Doporučené, Kvalitní, Značkové, Základní |
| Output: | 400 m3/h |
| Power consumption: | 60 W |
| Current: | 0,26 A |
| Voltage: | 230 V |
