OG Crush Rosin Press Extractor 5T

Product detailed description

Universal hydraulic resin extractor OG Crush OG5T with anodised dual heating plates 76x127 mm ensures perfect extraction using pressure and heating technology.

Advantages and features:
- manual rosin press with anodised dual heating plates for the best extraction experience anywhere
- 76 x 127mm anodised dual heating plates remain perfectly aligned during pressing
- plate size is suitable for most extraction bags and pre-press moulds
- PID with precise temperature sensor
- long service life
- strong compact steel frame, paired with a 5-ton hydraulic jack
- strong spring
- easily replaceable hydraulic jack
- food-grade aluminium work surface guarantees great taste and easy cleaning
- ideal pressure for pressing 1 – 12 g of flowers
- integrated 5-ton hydraulic jack delivers more than 1,000 PSI when pressing with 330 mm2 rosin extraction filters
- double insulation layers allow the rosin heating plates to reach 200 °F / 93 °C in 8 – 10 minutes and protect the machine from heat loss
- portable and compact, saves space and allows quick storage

Specifications:
- temperature range: 0 – 399 °F / 0 – 204 °C
- power: 500W
- voltage: 220 V
- total weight: 22 kg
- package size: 559 x 40 x 348 mm
- pressing area: 76 x 127 mm

Safety precautions when replacing the original hydraulic jack:
- do not replace the hydraulic jack with one over 5 tons
- choose a jack with a similar height and size / diameter
- place the jack head into the circle on the bottom plate
- there is no need to lock the jack in the lower part

Recommendations:
- to prevent leakage, do not release the bleed valve beyond 720 degrees (2 full turns)
- open the bleed valve slowly with half a turn
- do not replace the hydraulic jack with one over 5 tons
- one-person operation
- keep out of reach of children

PID controller settings:
- to increase and decrease the value in hundreds, tens and ones, press the ? button
- press the ? or ? button from 0 to 9 for the desired temperature
